Description
Kernel Handheld 308nm Excimer LED UVB Lamp, Light Intensity 30 mw/cm² – KN4003B3 – Higher Intensity, Higher Targeting, Precise Phototherapy for Localized Vitiligo on Face, Hands and Feet
Introducing the 308nm Excimer LED Lamp, KN4003B3 – an innovative, advanced, and safe home phototherapy solution for various skin conditions unresponsive to topical therapy, including:
- Vitiligo
- Moderately severe localized psoriasis
- Eczema
-
Parapsoriasis
-
Atopic dermatitis
- Pityriasis rosea
Achieve clearer skin and visible re-pigmentation in as little as two months.
Powered by advanced LED technology, KN4003B3 emits pure 308nm narrowband light that closely mimics 308nm excimer laser output. With dual treatment modes, lightweight handheld design and enhanced targeting precision, KN4003B4 delivers effective, safe, and affordable 308 excimer light therapy—at home or on the go.
- Suppressing the cutaneous cell-mediated immune response
- Speed up skin re-pigmentation
- Reduce itching, swelling and inflammation
- Smooth and shrink raised red, scaly or patches
Product Highlights
Convenient, Effective Alternative to Frequent Doctor Visits
- Utilizes 308nm Excimer LED light, a clinically proven wavelength that delivers stronger energy per second compared to 311nm, resulting in faster and more noticeable improvements with fewer treatment sessions.
Highly-targeted Therapy for Localized Areas
- With an 1.24 in² ± 10% treatment size, the KN4003B3 ensures precise treatment, focusing on affected skin while protecting surrounding healthy areas.
User-Friendly Time-Based Dosage Control
- Designed with time mode, allowing users to adjust each treatment session's duration to achieve the recommended dosage for their specific condition.
Other Product Features
✔ Stable & Long-Lasting Light Source – High-quality LED technology ensures a consistent, reliable light source with a 3,000-hour lifespan.
✔ Compact & Portable – Small, lightweight, and easy to carry, enabling continuous treatment anytime, anywhere, even while traveling.
✔ Rechargeable & Convenient – Powered by a built-in rechargeable battery with a USB Type-C charging port, allowing up to 35 minutes of uninterrupted use per full charge without losing intensity.
Why 308nm is better than 311nm?
- Faster Results – 308nm delivers stronger energy per second than 311nm. On average, it takes 20 times of treatment to achieve obvious results.
- Higher Targeting – The 308nm wavelength directly targets immune cells responsible for skin inflammation, helping to stop flare-ups and speed up healing.
- Safer – The 308nm wavelength allows for precise targeting of affected areas while reducing unnecessary UV exposure to healthy skin. The treatment is painless, with only a slight warming sensation. It is safe for children, infants, and even pregnant women.
Treatment Guidelines for Phototherapy
Initial Dose & Incremental Adjustments
- Vitiligo: 150-200 mJ/cm²
- Psoriasis: 300 mJ/cm²
Body Areas and Dose Adjustments:
- Face and Perineum: 150-180 mJ/cm²
- Increment Adjustments:
- No redness: +50-80 mJ/cm²
- Redness lasting <12 hours: +30-50 mJ/cm²
- Redness lasting 1 day: Maintain dose
- Redness lasting >1 day: Reduce dose
- Increment Adjustments:
- Hand Palm and Foot: 400 mJ/cm²
- Increment Adjustments:
- No redness: +200 mJ/cm²
- Increment Adjustments:
- Trunk, Limbs: 200-250 mJ/cm²
- Increment Adjustments:
- No redness: +100 mJ/cm²
- Redness lasting <12 hours: +50 mJ/cm²
- Increment Adjustments:
Instruction for Use
Pre-Treatment Steps:
1. Bathing: Take a 15-20 minute bath to remove skin scales.
2. Determine MED: Minimum Erythema Dose (MED) must be calculated before treatment.
- Kernel KN4003B4 Lamp Intensity: 30 mW/cm²
- MED Formula: Irradiation Time (seconds)=Dose (mJ/cm²) ÷ Lamp Intensity (mW/cm²)
Treatment Protocols
- Psoriasis:
- Frequency: 3-4 times/week
- Treatment session: 15-20 times
- Vitiligo:
- Frequency: 2-3 times/week
- Treatment session: 30-50 times or more
Dose Adjustment Guidelines:
A. No Erythema or Previous Erythema Resolved:
- Increase dose by 20-25%.
B. Mild Erythema:
- Maintain the same dose or increase by 10%.
- If resolved, follow "A."
C. Asymptomatic Shiny Erythema:
- Skip one treatment, then resume with the same dose.
- Gradually increase by 10% for subsequent sessions.
D. Painful Erythema with Edema or Blisters:
- Stop treatment until recovery.
- Resume at half the previous dose.
Business Transparency
Kernel, founded in 1997, is dedicated to research, development, and manufacturing in the high-tech medical equipment industry, with leading innovations in UV phototherapy devices, colposcopes, and PDT photodynamic therapy devices. Headquartered in Jiangsu, China, Kernel has offices in more than 30 countries and regions worldwide and is widely praised for its quality, effectiveness, and after-sales service. Kernel's products have been approved by the FDA, CE, and ISO 9001. Ahead of its peers in the medical equipment field, Kernel is also a supplier to the United Nations.
14-Day Return Policy
- Customers may return eligible products within 14 days of delivery for a refund or exchange.
- For hygiene and safety reasons, opened or used products cannot be returned unless defective or faulty.
- A 20% restocking fee applies to all returns except defective. We will repair, replace, or refund defective items free of charge.
- For full details, please refer to our Return Policy under the Warranty tab.
Comparison Chart
| Product Model | KN4003BL | KN4003B3 | KN4003B4 |
KN5000C | KN308E |
 |
 |
 |
 |
 |
|
|
Setting |
Home and travel |
Clinics, hospitals and home |
|||
|
Name |
Corded, Handheld 311nm UVB Lamp |
Cordless, Handheld 308nm Excimer LED UVB Lamp |
Cordless, Handheld 308nm Excimer LED UVB Lamp PRO |
Excimer Laser 308nm - Highest Intensity and Precision UVB Lamp |
Excimer LED 308nm - High-power UV Lamp |
|
Price |
$288.4 |
$664 |
$773 |
$2,999.48 |
$3,039 |
| Application | Psoriasis and vitiligo affecting slightly larger areas of the skin—such as the face, scalp, neck, hands, and feet. |
- Localized vitiligo - Moderately severe localized psoriasis - Moderately severe eczema, atopic dermatitis, pityriasis rosea and other autoimmune skin conditions unresponsive to topical treatments |
– Patients with a longer history of more severe Vitiligo conditions. – Patients who have not seen any improvement from other treatments. |
||
| Lamp Intensity | 4.5mw/cm² | 30 mw/cm² | 40 mw/cm² | 50 mw/cm² | 60 mw/cm2 |
| Treatment Size | 8.5 in² ± 10% | 1.24 in² ± 10% | 1.24 in² ± 10% | 3.1 in² ± 10% | 3.1 in² ± 10% |
| Light Source | 1 x 311nm UVB Light 311nm ± 3nm | 1 x UV LED | 1 x UV LED | XeCl Excimer Laser 308nm ± 2nm | High-power UV LED |
| Treatment Speed | Fast | 6.7X Faster | 8.8X Faster | 10X Fastest | 10X Fastest |
| Working Mode | Time | Time | Time and Dosage | Time and Dosage | Time and Dosage |
| MED Test | No | No | Yes | Yes | Yes |
| Work Distance | 1.18 in ± 0.20 in | 1.18 in ± 0.20 in | 1.18 in ± 0.20 in | 1.18 in ± 0.20 in | 1.18 in ± 0.20 in |
| Power source | Corded | Cordless, Built-in Rechargeable Battery, up to 35 minutes | Cordless, Built-in Rechargeable Battery, up to 25 minutes | Corded | Corded |
| Light Source Lifespan | ≤ 500h | ≤ 3,000h | ≤ 3,000h | ≤ 500h | ≤ 30,000h |
| Package | KN4003BL, cord, UV-proof glasses, instruction | KN4003B3, UV Googles, Charging Cable, Dust-proof Pouch, Whipping Cloth, User Manual | KN4003B4, UV Googles, Charging Cable, Dust-proof Pouch, Whipping Cloth, User Manual | KN5000C, cord, 6 x shades, UV-proof glasses, 1 x aluminum case and instructions | KN308E, cord, 6 x shades, UV-proof glasses, 1 x aluminum case and instruction |
Details
Delivery: |
Free shipping 7 - 10 Days |
Application: |
Vitiligo |
Setting: |
Home and Travel |
Brand Name: |
Kernel |
Product: |
Portable 308nm Excimer LED for Home and Travel |
Model: |
KN4003B3 |
Certificate: |
FDA Approved |
Wavelength: |
308 nm ± 3 nm |
Light Source: |
UV LED |
Light Intensity: |
30 mw/cm² |
Treatment Size: |
1.24 in² ± 10% |
Treatment Speed: |
6.7x Faster |
Treatment Mode: |
Time |
Work Distance: |
1.18 in ± 0.20 in |
Built-in MED Test: |
Y |
Mobility: |
Portable |
Built-in Battery: |
Y |
Battery Life after Fully Charged: |
35 min |
Power Source: |
100-240V |
Screen: |
Basic LED Screen |
Light Source Lifespan: |
≤ 3,000h |
Packing List: |
1 x KN4003B3, 1 x UV Goggles, 1 x Charging Cable, 1 x Dust-proof Pouch, 1 x Whipping Cloth, 1 x User Manual |
Dimension: |
8.66'' H x 2.09'' D x 2.6''W |
Product Weight: |
0.66 lbs |
